COLORDASH ACCENT QUAD FIXTURE 5-PIN XLR COMPLETE

Colordash Accent Quad delivers a tremendous punch of evenly mixed light into tight locations. Powered by a 10 W quad-color (RGBA) LED, this palm-sized fixture excels at delivering saturated colors and brilliant pastels with a soft, even glow. An onboard OLED display effortlessly controls and addresses the fixture via DMX or in a stand-alone mode.

Specifications

Optical

• Light Source: 1 LED (quad-color RGBA) 10 W, (700 mA), 50,000 hours life expectancy
• Beam Angle: 15°
• Field Angle: 29°
• Illuminance (total): 140 lux @ 5 m
• PWM Frequency: 1,200 Hz

Dynamic Effects

• Dimmer: Electronic
• Shutter/Strobe: Electronic
• Strobe Rate: 0 to 33 Hz
• Standalone Color Mixing: Yes
• Dim Modes: 4
• Built-in Automated Programs: Yes

Construction / Physical

• Dimensions: 4.3 x 2.6 x 6.8 in (110 x 67 x 172 mm)
• Weight: 1.8 lb (0.8 kg)
• Exterior Color: Black

Connections

• Power Connection: Edison plug to hard-wired
• Power Input: Hard-wired
• Data Connectors: 5-pin XLR DMX input and output cable whips
• Cable Length (power): 3.5 ft (1.07 m)

Control

• Control Protocol: DMX
• DMX Channels: 4, 6 or 10
• Modes/Personalities: 3 personalities (4CH, 6CH, 10CH)


Electrical

• Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
• Power and Current: 14 W, 0.20 A @ 120 V, 60 Hz
• Power and Current: 14 W, 0.13 A @ 208 V, 60 Hz
• Power and Current: 13 W, 0.12 A @ 230 V, 50 Hz


Certifications / Qualifications

• CE, MET
• IP Rating: IP20, dry location
